Versatility of the LEF-300
The LEF-300 puts flatbed printer production into overdrive with a larger print area and faster print speeds – approximately 1.6 times faster.
A Whole New Level of Speed and Production
The LEF-300 puts flatbed printer production into overdrive with a larger print area and faster print speeds – approximately 1.6 times faster than previous models when in CMYK mode. It allows users to take their graphic production and print customization to the next level.
Achieve High-Quality on a Wide Range of Materials
While a vacuum table makes it easy to hold thin materials in place, the LEF-300 is also able to accommodate items up to 3.94 inches in height. With the LEF-300, you can print on a wide variety of substrates such as PET, ABS, and polycarbonate, and soft materials such as TPU and leather, as well as three dimensional items, including pens, smartphone cases, signs, personalized awards, giftware, promotional items, laptop covers and more. The possibilities are virtually endless.
Advanced ECO-UV Inks for Outstanding Results
Designed for flexibility, ECO-UV inks image beautifully and conform around the most complex corners and curves, allowing users to customize everything from gifts and novelties to industrial parts and product prototypes.
Create Textures and Embossing Effects with Gloss Ink.
ECO-UV ink options include high-density white ink for greater brilliance on clear or dark-colored materials and Gloss ink for gloss and matte finishes. Multiple layers of clear ink can be applied to simulate embossing and 3D textures, and the included VersaWorks Dual RIP software comes with 72 ready-to-use texture patterns.
Automatic Height Adjustor
When printing on 3D items, the LEF-300 features a height adjuster that automatically moves the flatbed printer table back and forth until it reaches the required height. This automatic function also ensures quality print production by maintaining an optimum distance between the print head and the material surface.
| Printing technology | Piezoelectric inkjet | ||
|---|---|---|---|
| Media | Dimensions | Max. 31.5 (width) x 14.2 (length) x 3.94 (height) in. Max. 800 (width) x 360 (length) x 100 (height) mm |
|
| Weight | Max. 18 lbs. Max. 8 kg |
||
| Printing width and length |
Max. 30.3 (width) × 13 (length) in. Max. 770 (width) x 330 (length) mm |
||
| Ink cartridges |
Type and capacity | ECO-UV 220 cc cartridge, ECO-UV 500 cc cartridge (White ink is not available in 500 cc cartridges) |
|
| Colors | 6 colors (cyan, magenta, yellow, black, white, and gloss) | ||
| Print resolution (dpi) | Max. 1,440 dpi |
||
| Distance accuracy * | Error of less than ±0.3 mm (±11.8 mil) or ±0.3% of the specified distance, whichever is greater | ||
| Dryer *4 | Error of less than ±0.2 mm (±7.9 mil) or ±0.1% of the specified distance, whichever is greater | ||
| Connectivity | Ethernet (10BASE-T/100BASE-TX, automatic switching) | ||
| Power-saving function | Automatic sleep feature | ||
| Power requirements | AC 100 to 240 V ± 10%, 2.1 A, 50/60 Hz | ||
| Power consumption | During operation | Approx. 178 W | |
| Sleep mode | Approx. 18 W | ||
| Acoustic noise level | During operation | 60 dB (A) or less | |
| During standby | 49 dB (A) or less | ||
| Dimensions | 61.4 (width) × 37.6 (depth) × 22.7 (height) in.
(1,560 (width) × 955 (depth) × 576 (height) mm) (When the ink-cartridge tray is attached; 73.5 × 37.6 × 22.7 in. (1,866 × 955 × 576 mm) |
||
| Weight | 317.5 lbs. (144 kg) | ||
| Environment | Power on | Temperature: 20 to 32°C (68 to 90°F) (22°C [72°F] or higher recommended), Humidity: 35 to 80% RH (non-condensing) |
|
| Power off | Temperature: 5 to 40°C (41 to 104°F), Humidity: 20 to 80% RH (non-condensing) |
||
| Included items | Power cord, RIP & PRINT MANAGEMENT SOFTWARE (Roland VersaWorks Dual), User's Manual and Pad trays, etc. | ||
