How it Works
The ARM-10 uses Digital Light Processing (DLP) stereolithography 3D printing that prints layer-upon-layer of resin material which, once exposed to UV light, hardens into a semi-transparent object. This layered projection system of adding and curing converts a digital image created in 3D software into a solid object. By using a suspended build system, resin usage is kept to a minimum, making model production efficient and affordable.
Distinguishing Features
| ARM-10 | |
|---|---|
| Build technology | DLP layer projection system |
| Build size | 5.1 (W) x 2.7 (D) x 2.7 (H) inches (130 (W) x 70 (D) x 70 (H) mm ) (Job volume of resin is up to 0.7 lbs (300 g)) |
| Build speed | .393 inch (Layer pitch = 0.0059 inch) (10 mm/h (Layer pitch = 0.15 mm)) |
| Light source | UV-LED (ultraviolet light emitting diode) |
| XY resolution | .0079 inch (0.2 mm) |
| Z axis resolution | .0004 inch (0.01 mm) |
| Power | Machine：DC 24 V, 0.6 A Dedicated AC adapter: AC 100 V to 240 V±10%, 50/60 Hz |
| Power consumption | 15 W |
| Acoustic noise level | During operation: 55 dB (A) or less During standby: 49 dB (A) or less |
| Dimensions / Weight | 17.0 (W) x 14.4 (D) x 17.8 (H) inches / 37.5 lbs 430 (W) x 365 (D) x 450 (H) mm / 17 kg |
| Interface | USB |
| Accessories | AC adapter, Power code, USB cable, Liquid material tray, Printing and washing tools (Metalic spatula, Plastic spatula, Tweezers, Washing container x 2, Hexagonal wrench, Spanner, Rubber gloves, Work tray, etc.), Start-up page information card, Read this first. |
